Why I Built kaggle-vllm: Reproducible vLLM Inference on Dual NVIDIA T4 GPUs

Problem

The engineering question behind kaggle-vllm is narrow:

How can an upstream vLLM CUDA runtime be delivered into a managed Kaggle notebook without silently replacing the Python, PyTorch, or CUDA stack that the notebook already provides?

This is not primarily an API-design problem. It is a compatibility and provenance problem. A native inference runtime sits at the intersection of the Python ABI, PyTorch, CUDA, the NVIDIA driver, NCCL, compiled extensions, GPU architecture, and model representation. If any layer drifts, a command that looks like a normal package installation can produce an environment that imports incorrectly—or one that imports but no longer matches the system that was tested.

The public kaggle-vllm README defines the response: validate the host, resolve an immutable runtime artifact, verify its checksum, stage it without dependency resolution, and keep the dependency overlay separate. The project explicitly does not claim to be a vLLM fork or a new inference engine.

Why it matters

Managed GPU environments are productive precisely because much of the stack is already installed. That convenience creates a constraint: replacing one low-level dependency can invalidate the rest of the image.

For inference engineering, reproducibility requires more than saving a notebook. A useful experiment must answer:

• Which exact source revision produced the runtime?
• Which Python and CUDA ABI was the wheel built for?
• Which host libraries remained in place?
• Which GPUs and topology were visible?
• Which configuration was requested?
• Where are the logs and machine-readable results?

Without those identities, a successful output string is evidence only that something ran. It is not enough to compare tensor-parallel configurations, diagnose a collective, or reproduce a regression.

Environment

The first strong compatibility claim is intentionally limited to the committed profile below. These values come from the repository’s machine-readable compatibility manifest, not from assumptions about Kaggle or T4 systems in general.

Component	Validated value
GPU	2 × NVIDIA Tesla T4
GPU architecture	compute capability 7.5 / SM75
CUDA toolkit	12.8.93
NVIDIA driver	580.159.04
Python	CPython 3.12.13 / cp312
PyTorch	2.10.0+cu128
NCCL	2.27.5
vLLM source	v0.18.1 at a26e8dc7ff2111a005144d775ecf9cebf56c45b2

The table is a compatibility boundary, not a promise that every notebook image, T4 host, CUDA release, or vLLM version behaves identically.

Architecture

The delivery path separates validation, immutable resolution, native staging, and activation:

flowchart TD
    C[Notebook client] --> K[kaggle-vllm SDK]
    K --> D[Doctor: validate host contract]
    K --> R[Resolve immutable wheel]
    R --> H[Verify SHA256]
    H --> S[pip --target --no-deps]
    K --> O[Locked dependency overlay]
    S --> M[Runtime manifest]
    O --> M
    M --> V[Upstream vLLM]
    V --> G0[GPU 0: Tesla T4]
    V --> N[NCCL collective]
    N --> G1[GPU 1: Tesla T4]

This is a boundary-of-responsibility diagram. The SDK owns validation, artifact resolution, checksum verification, safe staging, activation, and thin wrappers. Upstream vLLM remains responsible for kernels, scheduling, model execution, tensor parallelism, and serving. The same separation is documented in the repository’s architecture note.

Hypothesis

The working hypothesis was that a compatibility layer could preserve the managed base image while making the runtime identity explicit:

1. Refuse unsupported host identities instead of guessing.
2. Pin the native artifact by immutable revision and SHA256.
3. Stage the native wheel with dependency resolution disabled.
4. Put missing Python dependencies in a separate overlay.
5. Activate paths explicitly and record them in a manifest.

This design does not predict throughput. It only creates the conditions under which later performance experiments can be interpreted.

Relevant implementation

The public dual-GPU example is deliberately small. The selected excerpt below is from examples/dual_t4_tp2.py at the source commit recorded in this article.

from vllm import SamplingParams
from kaggle_vllm import KaggleLLM

llm = KaggleLLM(
    model="facebook/opt-125m",
    tensor_parallel_size=2,
    max_model_len=512,
    gpu_memory_utilization=0.40,
)
outputs = llm.generate(
    ["NCCL is used by distributed GPU applications to"],
    SamplingParams(temperature=0.0, max_tokens=32),
)

The code is not presented as a performance result. It shows the minimum configuration surface for a dual-device smoke run.

The corresponding compatibility identity is data, not prose:

{
  "profile_id": "kaggle-py312-torch210-cu128-sm75-t4x2",
  "python": "3.12.13",
  "torch": "2.10.0+cu128",
  "cuda_toolkit": "12.8.93",
  "gpus": 2,
  "gpu_name": "Tesla T4",
  "compute_capability": "7.5"
}

The publishing workflow records the same provenance declaratively:

source:
  repository: kaggle-vllm/kaggle-vllm
  ref: 39f194eebf56c44e0f56bff54c1123a41725c049
code:
  - file: examples/dual_t4_tp2.py
    lines: "3:16"
    language: python

Experiment

The first experiment is operational rather than comparative: prove that the environment, artifact, and activation path agree before asking a performance question.

The repository documents this sequence:

python -m pip install "kaggle-vllm[hub]==0.2.0"
kaggle-vllm bootstrap --strict --dry-run
kaggle-vllm bootstrap --strict
eval "$(kaggle-vllm env)"
kaggle-vllm doctor --strict

The dry run matters. It exposes the selected profile and paths before the runtime is downloaded or staged. The strict doctor then turns profile drift into an error rather than quietly broadening the project’s claim.

For later benchmark articles, the experiment record must preserve engine settings, workload settings, token counts, timing mode, topology output, telemetry availability, and limitations. The committed benchmark schema provides those sections.

Results

This introductory article does not publish a new benchmark. Its result is a traceable publication boundary:

Question	Evidence required before a claim is published
Did the intended runtime load?	strict doctor output, import path, artifact hash
Did both GPUs participate?	visible-device record, worker/rank logs, NCCL evidence
Was TP=2 faster?	controlled TP=1/TP=2 results with matched non-TP settings
Did topology matter?	captured topology plus an experiment that isolates the variable
Can another engineer reproduce it?	immutable source, exact commands, raw JSON/logs, limitations

No new latency, throughput, memory, or speedup number is claimed here. Later articles will ingest measurements from committed JSON or CSV artifacts rather than transcribing them by hand.

Interpretation

The useful output of this stage is not “dual GPU is faster.” It is a system in which that question can be tested without losing track of the runtime.

Tensor parallelism introduces communication as well as compute. Whether it helps depends on the model, batch and concurrency regime, partitioning, kernel path, topology, and collective cost. That is why the publication roadmap separates:

• basic dual-device correctness;
• tensor-parallel performance;
• measured NCCL/topology behavior;
• concurrency crossover;
• multi-node orchestration;
• pipeline parallelism.

Each is a different experiment, not a chapter in a predetermined success story.

For a decoder-only transformer, a useful planning equation for KV-cache storage is:

\[KV_{bytes} = 2 \times L \times H_{kv} \times D_h \times B_e \times S\]

where $L$ is the layer count, $H_{kv}$ the number of KV heads, $D_h$ the head dimension, $B_e$ bytes per element, and $S$ the sequence length. The factor of two accounts for keys and values. The equation is a capacity model; an experiment must still measure allocator behavior and runtime overhead for a specific engine configuration.

What failed

The design exists because the naive installation model is unsafe for this environment. The project architecture notes that a normal dependency-resolving vLLM installation may select a different Torch/CUDA set and disturb the managed image (source).

Another failure mode is epistemic: treating a generated response as a benchmark. A smoke test can establish basic execution. It cannot establish throughput, TTFT, TPOT, scaling efficiency, or the cause of a performance difference.

Limitations

• The compatibility profile is specific to the environment recorded above.
• A two-GPU smoke run is not a production-readiness test.
• Successful NCCL execution does not by itself characterize collective bandwidth.
• This article does not compare NVIDIA T4 with another accelerator.
• The KV-cache equation omits engine-specific allocation and fragmentation effects.
• The article introduces the evidence model but does not add a new measured result.

Reproduction

To inspect the exact source used for this article without touching another checkout:

git clone https://github.com/kaggle-vllm/kaggle-vllm.git
cd kaggle-vllm
git checkout 39f194eebf56c44e0f56bff54c1123a41725c049
git status --short
python -m pytest

GPU acceptance must run only in the documented environment and should write evidence to a new, inspected output directory. CPU tests validate tooling behavior; they do not substitute for GPU evidence.

Evidence

• Source repository at commit 39f194e
• Compatibility manifest
• Architecture and responsibility boundary
• Benchmark methodology and evidence schema
• Public releases

Next experiment

The next note will ask a controlled question: under a fixed model and workload, what changes when tensor parallel size moves from one to two on the documented dual-T4 host?

It will require matched engine settings, isolated runs, raw timing evidence, topology capture, and a clear distinction between capacity and performance.
